Features

• Memorized time off
• Random startup
• Remote temperature sensor optional
• Energy saving mode optional
• LCD display with simple user interface
• Room temperature or setpoint temperature display select-able
• Manual or automatic fan speed selectable
• Temperature units in either °C or °F
• User setting can be stored when power loss
• Freeze protection function available
• Keypad lock options
• Heating and cooling setpoint limitation

Specification

• Power supply : 24(±10%)VAC, 50/60Hz
• Modulating Output : DC 0~10V
• Accuracy : ±1°C at 21°C
• Auto Cycle times : 100,000 times
• Manual Cycle times : 10,000 times
• Set point range : 10 ~ 32°C
• Display range : 0 ~ 37°C
• Ambient operating limits : 0~ +49°C
• Ambient storage limits : -30 ~ +60°C
• Rated Impulse Voltage : 2500V
• Maximum Temperature : 155°C
