Specifications

Overview

Lead time

• Usually in Stock

Main

Main Input Voltage

• 220 V

• 230 V

• 240 V

Input Connection Type

• NEMA 5-15P

provided equipment

• User manual

Physical

Colour

• White

Height

• 10 cm

width

• 6.3 cm

Depth

• 4.15 cm

Net weight

• 0.14 kg

mounting preference

• No preference

mounting mode

• Not rack-mountable

Input

input power

• 2500 W

network frequency

• 50/60 Hz

maximum input current

• 10 A

Switching current capacity

• 10 A

Output

number of power socket outlets

• 1

Outlet standard

• NEMA universal

Conformance

Equipment protection policy

• No EPP for ASEAN

Environmental

Ambient air temperature for operation

• 0…40 °C

relative humidity

• 0…90 %

Operating altitude

• 0...10000 ft

Ambient air temperature for storage

• -5…40 °C

storage Relative Humidity

• Non-condensing 0…95 %

Storage altitude

• 0.00…4572.00 m

Surge Protection and Filtering

response time

• 1 ns common mode

Common mode rejection

• 30 dB

peak current

• 24 kA common mode

• 12 kA normal mode

Surge energy rate

• 918 J

Packing Units

Unit Type of Package 1

• PCE

Number of Units in Package 1

• 1

Package 1 Height

• 10.6 cm

Package 1 Width

• 8.8 cm

Package 1 Length

• 7 cm

Package 1 Weight

• 0.18 kg

Number of Units in Package 2

• 12

Package 2 Height

• 127.00 mm

Package 2 Width

• 279.40 mm

Package 2 Length

• 304.80 mm

Package 2 Weight

• 2.47 kg

Number of Units in Package 3

• 1008

SCC14

• 10731304336652

Contractual warranty

Warranty

• 10 years repair or replace
