Technical Specifications

Output

- Max Configurable Power (Watts) : 650 Watts / 1.2kVA

- Output Frequency (sync to mains) : 50/60 Hz +/- 1 Hz Sync to mains

- Topology : Line interactive

- Waveform type : Stepped approximation to a sinewave

- Transfer Time : 6 ms typical : 10 ms maximum

Input

- Input frequency : 50/60 Hz +/- 5 Hz Auto-sensing

- Input voltage range for main operations : 140 - 300 (230 V) ACV

- Number of Power Cords : 1

- Input Power Factor at Full Load : 0.51

Batteries & Runtime

- Battery type : Lead-acid battery

- Typical recharge time : 8hour(s)

- Nominal Battery Voltage : 12 V

- Expected Battery Life (years) : 3 - 5

- Battery Volt-Amp-Hour Capacity : 108

Communications & Management

- Control panel : LED Status display with on line : on battery

- Audible Alarm : Alarm when on battery : distinctive low battery alarm

Surge Protection and Filtering

- Surge energy rating : 273 Joules

Physical

- Maximum Height : 190MM, 19.0CM

- Maximum Width : 140MM, 14.0CM

- Maximum Depth : 390MM, 39.0CM

- Net Weight : 7.5KG

- Shipping weight : 8.5KG

- Shipping Height : 297MM, 29.7CM

- Shipping Width : 235MM, 23.5CM

- Shipping Depth : 495MM, 49.5CM

- Color : Black

- SCC Codes : 10731304404375

Environmental

- Operating Temperature : 0 - 40 °C

- Operating Relative Humidity : 0 - 95 (Non-condensing) %

- Operating Elevation : 0 - 3000meters

- Storage Temperature : -15 - 40 °C

- Storage Relative Humidity : 0 - 95 (Non-condensing) %

- Storage Elevation : 0 - 3000 meters

- Audible noise at 1 meter from surface of unit : 40.0dBA

- Protection Class : IP20

Conformance

- Approvals : CB , CE, EN/IEC 62040-1, EN/IEC 62040-2

- Equipment protection policy : Lifetime : 50000 euros

- Standard warranty : 2 years repair or replace
