Specification

Bluetooth Standard

5.2, 15m

Bluetooth Transmit

2x Bluetooth TX, able to connect up to 2 Bluetoothspeaker or earbuds.

Bluetooth Receiver

2x Bluetooth RX, able to connect up to 2 Bluetoothtransmitter device

Bluetooth Codec

aptX HD, aptX, AAC, SBC

Power Output

24V 4ohm 50W *2

24V 8ohm 30w *2

Speaker Impedance

4 - 8 ohm

Frequency Response

20Hz to 20Khz

SNR

>93db

THD+N

<0.03% @1kHz/1W/4ohm

Line in

Analog RCA, Max 2V RMS input

Phono in

Analog RCA, support MM/MC

Optical in

Max 192kHz/24bit sample rate decode PCM encoding

HDMI ARC

PCM only

USB Host

USB disk drive playback, support resume playback

Sample rate: 48kHz Storage format: Fat16, Fat32, exFAT, up to 128GB

Support codec: mp3(data rate up to 384kbps), mp4, wma, mov, m4a, aac, flac(96kHz/24bit), ape

Subwoofer out

Max 3V RMS output, Frequency Response: 250Hz

Speaker out

50W per channel @ 4ohms

Power Input

24V/4.16A, 32V(optional)

Size

185 x 155 x 50mm

Weight

900g
