Basic Specification:

● Size: 3"-3/8" (86 mm) diameter

● Dials: Metal, Black

● Bezel/Finish: Black

● Graphics/symbols: White-on-black English-metric (dual scale) with SAE symbols

● Pointer: Standard white; RTZ feature on select products

●Lens: Glass

● Case: High-impact moisture-resistant polyester (PBT)

● Bobin assembly: Fully sealed, internally dampened

● Movement: High-torque Magna-Torque air-core movement: 270° sweep for tachometers&speeedometers

● Lighting: Perimeter lighting (Flood-lit)/Optional incandescent 12- or 240 volt 5/8" or wege-base light kits

● Supply/operating voltage: 12 VDC or 24 VDC/ 10-16 VDC (12-volt) or 20-32 VDC (24-volt)

● Electrical connections: #6-32 studs, male

● Hardware: "Kit" includes mounting bracket, lock washers & zinc-plated nuts

● Sealing: Front sealed, gasketed

● General Performance: Gauges per SAE J 1810 ; meters per SAE J 1399 & J 1226

● Accuracy: Per SAE J 1810: +/- 1.5 angular degrees at primary calibration point & +/-3 angular degrees at secondary calibration point based on nominal input

● Operating temperature: -40°C to +85°C

● Shock & Vibration: Per SAE J 1810

.

Product:

1.Type Description: Tachometer (electrical)

Scale: 0-3,000RPM

Volt/Watt/Current: 12-24 VDC

Signal Source: Mag Tach
