Q Acoustics 3050i

Specifications

Crossover Frequency 2.5 kHz

Dimensions 1000 x 200 x 300 mm (39.4 x 7.9 x 11.7 in) cabinet

1020 x 310 x 317 mm (40.1 x 12.2 x 12.5 in) overall

Enclosure Type 2-Way Reflex

Frequency Response (+3 dB, -6 dB) 44Hz - 30kHz

Impedance 6 Ohm

Power Input 50-165W

Sensitivity 91dB (2.83 V@1 m)

Tweeter 22 mm (0.9 in)

Weight 17.8kg (39.2 lbs)

Q Acoustics 3030i

Specifications

Enclosure type: 2-way reflex

Bass unit: 165 mm (6.5 in)

Treble unit: 22 mm (0.9 in)

Frequency response (+/-3 dB, -6 dB): 46 Hz - 30 kHz

Average impedance: 6 Ω

Minimum impedance: 4 Ω

Sensitivity (2.83v@1m): 88 dB

Stereo amplifier power: 25 - 75 W

AV receiver power (2 ch. driven): 50 - 145 W

Crossover frequency: 2.4 kHz

Effective volume: 12.5 L (763 cu in)

Enclosure dimensions (HxWxD): 320x200x313

Overall dimensions (HxWxD): 325x200x329

Weight (per speaker): 6.4 kg (14.1 lbs)

Q Acoustics 3020i

Specifications:

Enclosure type: 2-way reflex

Bass Unit: 125 mm (5 in)

Treble Unit: 22 mm (0.9 in)

Frequency Response (+3 dB, -6 dB): 64 Hz – 30 kHz

Nominal Impedance: 6 Ω

Minimum Impedance: 4 Ω

Sensitivity (2.83 Vrms@1 m): 88 dB

Stereo Amplifier Power: 25 - 75w

AV Receiver (2 ch. driven): 50 - 75w

Crossover Frequency: 2.4kHz

Effective Volume: 6.1 L (372 cu in)

Dimensions H/W/D: 278 x 170 x 282 mm (11.0 x 6.7 x 11.1 in)

Weight (per speaker): 10.59 lbs / (4.8 kg) per speaker

Q Acoustics Q3090ci

Specifications:

Enclosure type: 2-way reflex

Bass Unit: 2 x 100 mm (4 in)

Treble Unit: 22 mm (0.9 in)

Frequency Response (+3 dB, -6 dB): 75 Hz – 30 kHz

Average Impedance: 6 Ω

Minimum Impedance: 4 Ω

Sensitivity (2.83 Vrms@1 m): 89 dB

Stereo Amplifier Power: 25 - 100 W

AV Receiver (2 ch. driven): 50 - 165 W

Crossover Frequency: 2.7 kHz

Effective Volume: 6.6 L (403 cu in)

Dimensions H/W/D mm: 152 x 430 x 216 mm (6.0 x 16.9 x 8.5 in)

Weight (per speaker): 6 kg (13.2 lbs)
