SPECIFICATIONS

Frequency Range

130Hz - 30kHz +/- 3dB 113Hz - 32kHz +/- 6dB 93Hz - 36kHz +/- 10dB

High Frequency Driver

1" (2.54cm) Aluminum Dome Tweeter mated to an all new 105º custom Tractrix® horn

Low Frequency Driver

5" (12.7cm) IMG Woofer

Sensitivity

88 dB

Coverage Angle

105°

Power Handling

60W Peak

70V / 100V Tap Setting

70V: 3.75W, 7.5W, 15W, 30W 100V: 7.5W , 15W, 30W 8 Ohm Bypass

Enclosure Type

UV Treated, Glass-Filled ABS Cabinet

Finish

Brown Matte, Paintable

Product Dimensions

6.3” x 6.85” x 8.5” (160mm x 174mm x 216mm)

Product Weight

5 lbs (2.27 kg)

Accessories

PRO-10-GS 10” Ground Stake (PN: 1063447)

Built From

• 2016
