The A11MKII Integrated Amplifier delivers the ideal combination of power and connectivity for anyone seeking to elevate their listening experience.

Constructed around a massive Rotel-built toroidal power transformer, the A11MKII delivers 50 Watts per channel of Class A/B power into 8 ohms supporting analog, digital and Moving Magnet Phono stage inputs.

The A11MKII Integrated Amplifier offers an ideal combination of power and connectivity for the music lover seeking to elevate their listening experience.

Constructed around a linear power supply featuring a massive Rotel-built toroidal power transformer, the A11MKII delivers an authoritative 50 Watts per channel of Class A/B power into 8 ohms, and even higher power into demanding loudspeakers.

Both analog and digital sources are welcome, with three line-level RCA inputs, coaxial and optical digital inputs, a Moving Magnet Phono stage, and aptX™ HD Bluetooth. An 1/8” headphone jack with dedicated headphone amplifier circuit is provided on the front panel for private listening sessions.

The intuitive front panel layout includes Bass, Treble, and Balance rotary controls and source input selection ensuring the A11MKII is personal and a pleasure to operate up close. The included IR remote drives a motorized analog volume controller for ease of use at the listening position.

The A11MKII is available in both black and silver colors.

Power Output

50W/Ch (8Ω)

62W/Ch (4Ω)

Total Harmonic Distortion (THD)

<0.03%

Frequency Response

Line Level Inputs: 10Hz - 100kHz, -0.5dB, +0.05dB

Phono Input: 20Hz - 20kHz, -0.5dB, +0.3dB

S/N Ratio (IHF "A" Weighted)

Line Level Inputs: 90dB

Phono Input: 85dB

Dimensions (W × H × D)

430 × 73 × 347mm

17” x 2 7/8” x 13 5/8”

Front Panel Height

60 mm (2 3/8”)

Power Requirements

230V, 50Hz

Power Consumption

150W

Standby Power Consumption

<0.5W

Net Weight

6.8kg (15lbs.)

BTU Rating (4Ω, 1/8th power)

450 BTU/h

Intermodulation Distortion (60Hz:7kHz, 4:1)

<0.03%

Damping Factor

120

Input Sensitivity

Line Level Inputs: 130mV

Phono Input (MM): 1.6mV

Input Impedance

Line Level Inputs: 45kΩ

Phono Input (MM): 43kΩ

Input Overload

Line Level Inputs: 4V

Phono Input: 50mV

Tone Controls

±6dB at 100Hz / 10kHz
