สเปค

Gain:  40 dB @ 1 KHz (MM)

          52 dB @ 1 KHz (MC)

          62 dB @ 1 KHz (MC)

          72 dB @ 1 KHz (MC)

RIAA Response:  +0.1 dB 20-20 KHz

Distortion:  < .05 % THD @ 20 volts balanced @ 1 KHz

Maximum Output:  20 volts rms.

Output Impedance:  150/150 ohms

Input Impedance: 47 Kohm 0-550 pF (MM)

                          33 ohm - 47 Kohm (MC)

Unweighted Noise:  -90 dB ref. 10 mV input (MM)

                             -81 dB ref. 1 mV input (MC)

Power Consumption:  32 Watts

Number of Chassis:  2

Dimension (WxHxD):  Main Unit: 432 x 100 x 320 mm.

                                Supply Unit: 163 x 79 x 233 mm.

Weight:  Main Unit: 6.5 Kg, 8 Kg in shipping carton

              Supply Unit: 3 Kg, 3.3 Kg in shipping carton
